The 3 in 1 handheld laser welding machine adopts an integrated design concept, which greatly reduces the size of the welding machine, reduces the floor space, and makes mobile use more convenient. It adopts a lightweight intelligent swing welding head (weighing about 0.8kg), with adjustable weld bead width, wider application range, more flexible and simple operation, and no need for professional welder skills.
As a laser welder, the welding seam is smooth and beautiful, with no need to polish, no deformation or welding scar, and firm welding of the part. Save time and improve efficiency.
As a laser cleaner, it Can clean rust, paint, resin, coatings, oil, and stains. It is a "green" cleaning method. It does not need to use any chemical agent or cleaning solution. The cleaned waste is basically solid powder. It is small, easy to store, and recyclable. It can easily solve the problem of environmental pollution caused by chemical cleaning.
As a laser cutter, it is very easy to operate to cut all types of metals.
ADVANTAGE
Handheld Welding Gun
The gun body has stronger dust-proof and anti-interference capabilities, is lighter in weight (0.8kg), is more flexible to use, and is easier to operate; Oscillating welding gun, maximum welding width 8mm, a maximum swing speed of 10000mm/s, supports up to 30m motor cable (customization is supported);
Using high-power lenses, it can withstand up to 4000W, and the transmittance and reflectivity are above 99.8%; The protective mirror and focusing mirror adopt a drawer-type design, making maintenance and replacement more convenient and improving work efficiency.
Auto Wire Feeder
Intelligent filling welding seam is beautiful and the quality is up to standard. Increase work efficiency.
In order to achieve a stable wire feeding process, users need to choose according to the material of the workpiece, welding parameters, wire type, etc.
Centralized control of the welding gun and wire feeder, including "one-button wire feeding" and "one-button wire rewinding", easy to operate, and supports dual-channel wire feeding.
Air pressure protection
Air pressure protection system
If the air pressure is too low, the laser will be automatically turned off;
Alarm prompt for low air pressure;
The air pressure warning value is independently adjustable;
Real-time display of input air pressure;
Easy to Move
Integrated design, the welding machine is small in size and occupies a small area。 the volume is only 0.41 m³ easy to put in a car.ergonomic design easy to push.making it more convenient to move and use.
PARAMATERS
| Handheld Laser Welding Machine Technical Parameters | |
| Machine Model | NX-2000W |
| Galvanometer Width | 0-8mm |
| Welding speed | 0-120mm/s |
| Operating Ambient Temperature/Humidity Range | “-15℃-35℃ ＜70% Condensationless |
| Welding Depth | ＜5mm |
| Barometric Pressure Protection | Yes |
| Operating Voltage | 220±20V |
| Power of the Whole Machine | 8KW |
| Product Dimension | Main Unit Size：1000*550*750mm Wire Feeder Size：600*230*450mm |
| Fibre Laser Main Parameters | |
| Power (Output) | 2000W |
| Wavelength Range | 1080±10nm |
| Fibre Core Diameter | 20um，25um or 50um |
| Fibre Optic Cable Length | 12m |
| Output Connector | QBH |
| Indicator Light | Red Light |
| Operating Mode | Continuous or Modulated |
| Direction of Polarisation | Stochastic |
| Output Power Stability（25℃） | ＜±1.5% （2h） |
| Power Adjustment Range | 10%~100% |
| Maximum Modulation Frequency | 5KHz |
| Control Mode | RS232 |
| Power Consumption | 6.0KW |
| Input Voltage | 220±20V 50HZ/60HZ |
| Cooling Method | Water Cooling |
| Water Chiller Main Technical Parameters | |
| Operating Power/Frequency | 220V 50HZ/60HZ |
| Power of the Whole Machine | 2.1KW |
| Operating Current | 10-12A |
| Temperature Control Precision | ±1℃ |
| Cooling Capacity | 4500 |
| Refrigerants | R22a |
| Power of Electric Auxiliary Heat | 0.75KW（Ordinary Temperatures） |
| Pump Rated Flow Rate | 64L/min |
| Maximum Pump Head | 32m |
| Water Pump Power | 0.3KW |
| Water Tank Volume | 19L |
| Operating Environment | Ambient temperature ≥45℃, relative humidity ≥95%RH |
| Welding Torch Parameters | |
| Applicable Wavelength | 1050-1095nm |
| Scope of Application | ≤3000W |
| Collimation Focal Length | 60mm |
| Focus Length | 150-200mm |
| Protective Lenses | 18*2mm |
| Vertical Focus Range | ±10mm |
| Spot Adjustable Range | 0-8mm |
| Maximum Support Air Pressure | 15Bar |
| Fibre Optic Input Interface | QBH |
| Weight | 0.8KG |
| Cutting Function | Yes |
| Cleaning Function | Yes，Widest 80mm |
PRODUCT DETALS
Welding /Cleaning/Cutting Switch
Pure copper welding nozzle( dual-channel wire feeding optional), switching cutting kit, and cleaning kit.Laser welding, laser cutting, laser cleaning function conversion by changing Lens and Nozzle.
Pure copper welding nozzle
AS-12: Suitable for inner corner, outer corner, and flat filler wire welding, universal for 1.2mm and below welding wires; AS-16: Suitable for inner corner, outer corner, and flat filler wire welding, universal for 1.6mm welding wire;
BS16-8: Suitable for large welding width inner corner, outer corner, flat wire filler welding, 1.6mm wire pass
For use, the maximum welding width is 8mm;
C: Suitable for welding of inner corners, outer corners, and flat surfaces without filler wire;
CS-12: Suitable for outer corner filler wire welding, universal for welding wires of 1.2mm and below;
AS-16D: Suitable for inner corner, outer corner, and flat double filler wire welding, 1.6mm welding wire is universal;
AS-20D: Suitable for inner corner, outer corner, and flat double filler wire welding, 2.0mm welding wire is universal;
M8-1.5: Suitable for cutting, front light output diameter 1.5mm;
laser Source
Special laser for laser welding, with high industry brand awareness;
The beam quality is good, the photoelectric conversion rate is high, and the performance is stable;
Mobile APP software, Bluetooth connection, one-click fault detection;
Modular design, maintenance-free operation, low cost of use;
Intelligent control system
Three-in-one control system has multiple functions such as continuous welding, spot welding, fish scale welding, cleaning, and cutting, and can be used in multiple scenarios;
The control system uses a high-speed core processor and is equipped with multiple safety monitoring devices, with fast response and high safety performance;
The controller has high integration, strong anti-interference ability, compact size, convenient wiring, and easier installation and maintenance;
LCD touch screen, visual operation page, simple parameter setting, real-time monitoring and control data to ensure stable operation of the welding gun;
The process library can pre-store multiple welding process parameters, the process name can be modified freely, and different processes can be retrieved with one click;
Intelligent water cooling system
Integrated design concept, small size and easy to use;
Using high-power compressor, the cooling effect is better;
Adopt large-capacity water tank and high-pressure and high-lift magnetic water pump;
Adopting high and low temperature intelligent control system, the performance is stable;
Using LCD control panel, fault codes can be quickly queried;
TRADITIONAL WELDING & LASER WELDING
APPLICATION
PACKINH LIST
| Configuration name | quantity | ||
| 1 | fiber-optic laser | 1 | |
| 2 | Welding gun and control system | 1 | Welding, cutting and cleaning three-in-one system |
| 3 | Intelligent dual temperature chiller | 1 | |
| 4 | Air pressure protection system | 1 | Optional double wire feed device |
| 5 | Wire feed device | 1 | |
| 6 | Chassis sheet metal | 1 | |
| 7 | Special copper nozzle | 1 | |
| 8 | Protective lenses | 1 | |
| 9 | Laser protective glasses | 1 | |
| 10 | Toolkit | 1 |
