S&A Genuine CW-5000 Series (CW-5000DG/TG) Industrial Water Chiller Cooling Water
S&A Genuine CW-5000 Series (CW-5000DG/TG) Industrial Water Chiller Cooling Water
SKU:CW-5000TG
Mainly used for cooling
- 80W and below CO2 glass laser tubes;
- UV laser marking machines;
- UV curing system printers;
- Equipment with a cooling capacity of 1.08KW (3868Btu/h) or less.
- MCWlaser Official Quality Inspection (100% brand new original authentic).
- Secure payments; Lifetime Tech Support (Specialists).
- Support Shipping Worldwide, US and EU stock.
- Good customer service. Please contact us at info@mcwlaser.com.
Couldn't load pickup availability
Main Parmeter
*Machine power: 0.5KW
*Tank capacity: 7L
*cooling capacity: 1.08KW,3868Btu/h
*Refrigerant charge: 300g
*Max.flow:16L/min
Advantage
*Powerful Cooling Performance
*Precise Temperature Control
*Alarms and Protection Function
*Constant temperature and intelligent temperature two temperature control modes
Size & Weight
*Machine Size:58×29×47cm (L×W×H)
*Net Weight:24Kgs
Waranty
*Worldwide Waranty 2 Years
*Free replacement parts during warranty period
Certification
*FDA Compliant
*CE Certification
*RoHS Certification
Manual Download










The S&A Industrial water chiller unit CW-5000 has a small size, but its cooling performance is excellent. It features a cooling capacity of 800W and temperature stability of +0.5°C.In addition, the water chiller CW-5000 is charged with environmentally friendly refrigerant R-134a to protect the environment.
To guarantee product quality, the water chiller CW-5000 has to go through a series of strict simulated laboratory tests, and the core components such as the evaporator, condenser, and sheet metals are independently developed by S&A.
Features
【Powerful Cooling】Genuine S&A CW-5000 water chiller uses standard R134a refrigerant with 300g charged to keep the laser cutting and engraving machine up to 80W-100W well and cool during use; Its 2.64gpm flow rate and 1.1hp compressor cools up to 3868 Btu per hour
【Large Capacity Water Tank】1.85 gallon (7L) water tank features a closed design to reduce water evaporation and provide long service between fills; Precision scale shows water level; Easy to observe and know when water filling is needed.
【High Quality Materials】Water inlet and outlet ports made from precision-engineered brass, it has long-term corrosion resistance; Friendly handle and customized dust-proof net; Dual cooling fans, high heat dissipating capacity.
【Precise Temperature Control】S&A industrial water coolers have dual mode temperature control (automatic and intelligent), They can keep the temperature constant within 0.3°C; Constant & Intelligent temperature mode; Automatically adjusts the temperature according to the indoor environment temperature; Manually set the temperature between 5-40 degree.
【Operational Safety】Our water coolers have multiple protection and alarm functions,automatic alarm prompt in case of abnormal flow;if the working water temperature is too high, it will give an automatic alarm;Compressor overcurrent protection: protect refrigeration stability.
【2 years warranty period】Two-year warranty and lifetime professional tech support.
Free spare parts and free replacement devices based on actual faults during the maintenance period.
Parameter and Structure
MODEL | CW-5000TG | CW-5000DG | CW-5000TI | CW-5000DI |
---|---|---|---|---|
Voltage |
AC 1P 220V |
AC 1P 110V |
AC 1P 220V |
AC 1P 110V |
Frequency |
50/60HZ |
60HZ |
50/60HZ |
60HZ |
Current |
0.4A~2.68A |
0.4A~4.42A |
0.8A~3.08A |
0.8A~4.82A |
Machine power |
0.44/0.46KW |
0.43KW |
0.51/0.53KW |
0.5KW |
Compressor power |
0.37/0.39KW |
0.38KW |
0.37/0.39KW |
0.38KW |
0.5/0.53HP |
1.14HP |
0.5/0.53HP |
1.14HP |
|
Nominal cooling capacity |
3037/3686Btu/h |
3868Btu/h |
3037/3686Btu/h |
3868Btu/h |
0.89/1.08KW |
1.08KW |
0.89/1.08KW |
1.08KW |
|
765/928Kcal/h |
928Kcal/h |
765/928Kcal/h |
928Kcal/h |
|
Refrigerant charge |
280g |
300g |
280g |
300g |
Pump Power |
0.03KW |
0.1KW |
||
Max.lift |
10M |
25M |
||
Max.flow |
10L/min |
16L/min |
||
N.W. |
24Kgs |
|||
G.W. |
27Kgs |
|||
Refrigerant |
R-134a |
|||
Precision |
±0.3℃ |
|||
Reducer |
Capillary |
|||
Tank Capacity |
7L |
|||
Inlet and Outlet |
OD 10mm barbed connector |
10mm fast connector |
||
Dimension |
58×29×47cm (L×W×H) |
|||
Package Dimension |
70×43×58cm (L×W×H) |
Note: the working current can be different under different working conditions; The above information is for reference only. Please subject to the actual delivered product.
lnstallation and Use
The following are the installation and use conditions of our water chillers for your reference.
Our water chiller is used for cooling water. If it is other liquids, please make sure there is no corrosion for the water chiller.
When using our water chiller, the water inlet of the water chiller needs to connect with the water outlet of your equipment, and the equipment water inlet connects with the water outlet of our water chiller. It is the closed loop
It is required to meet
1. The water flow is uniform
2. There is no impurity in the circulating water.
Application

Packaging list
* 1X Machine
* 1X User Manual
* 1X Notebook
* 1X Power Cord
* 1X Alarm Output Plug
* 1X Sealed Hoop
Maintenance
Cleaning and Antifreeze
1. To ensure good heat dissipation, please open the lid to clean the dirt after the cooler is used in the long term.
2. Ethanol can be used as a short-term antifreeze, but it is corrosive and needs to be emptied within a week.
Users in cold areas should use noncorrosive special antifreeze.
It is recommended to choose CLARIANT (Clariant) brand, there are two types of antifreeze suitable for laser systems:
1) Antifrogen-N glycol-water type (industrial products, toxic to human body)
2) Antifrogen-L propylene glycol-water type (food grade, harmless to human body)
Water Tank Water Exchange Method and Frequency
1. To exchange the water in the tank, drain the waste water out of the tank using the drain outlet, and refill the tank with clean water through the filling hole.
2.The frequency of water exchange is crucial for maintaining the quality of the circulating water and maximizing the service life of the laser tube. It is recommended to exchange the purified water once a month and the running water twice a month. It is also advised to use purified water for optimal performance.
Industrial water chiller unit CW-5000 has small size, but its cooling performance can not be overlooked. It features cooling capacity of 800W and the temperature stability of +0.3°C.
Small size and excellent cooling performance makes industrial water chiller unit CW-5000 a perfect choice for CO2 laser cutting machine users who don't have too much working
space.
CW-5000 water chiller is very popular among CO2 laser cutting machine users and it is the best selling refrigeration type water chiller unit.
In addition, compact water chiller CW-5000 is charged with environmental friendly refrigerant R-134a in order to protect the environment, which shows S&A is an environmentally responsible enterprise.
To guarantee the product quality, compact water chiller CW-5000 has to go through a series of strict simulated laboratory tests and the core components such as evaporator,
condenser and sheet metals are independently developed by S&A.
Industrial water chiller unit CW-5000 offers 220/110V 50/60Hz so that it has wider access to users in different countries. Besides, it has multiple alarm functions, such as compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm so that the chiller can be well protected.
Features
1.800W cooling capacity; use environmental refrigerant
2. Compact size, long working life and simple operation;
3. +0.3°C precisely temperature control;
4. The inelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions;
5. Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm;
6. Multiple power specifications; CE,RoHS and REACH approval;
7. Optional heater and water filter.
Specification
One-stop automatic itelligent temperature control: in different environment, user does not need to change setting due to it will automatically switch to appropriate operating temperature.
CW-5000: applied to cool CO2 laser tube;
CW-5000: applied to cool CNC spindle or welding equipment;
CW-5000 : applied to cool solid-state laser.
Contact form
The easies set up, put in distilled water and ran laser, the digital readout on front makes it easy to see water temps. Big plus is you can adjust it on main panel.
I had an issue with the original chiller that was sent to us. The compressor would not turn on and therefore it would not chill the water. The seller was contacted and they were very nice and easy to deal with. we started out by trying to do some self diagnosing to see if it was something that could easily be fixed on our end, but when we were not getting any results, they immediately shipped out another chiller no questions asked. The new chiller arrived and so far it is working perfectly.
This chiller is a perfect addon to any of the CO2 Chinese lasers and does a great job of keeping the temperature within it's set points. The only suggestion would be to ship it in constant temperature mode vs. intelligent mode. But easy enough to change it in settings...
Bought this for my 70 watt boss laser. Keeps its steady at 17C for hours great machine.
The machine works great! but the instructions to program are a little hard to understand. I eventually had to look it up on YouTube. After that easy! Highly recommend.
