MCWlaser 3W 5W UV Laser Marking Engraving Machine with Water Chiller

MCWlaser 3W 5W UV Laser Marking Engraving Machine.
10.64um/10600nm laser, laser thermal processing, engraving through the surface vaporization of the processing body, mainly used for non-metallic markings, such as metal, plastic, glass, and acrylic.High precision engraving, fast speed..

Key Advantages

1. Perfect marking quality: 355nm output wavelength to reduce the thermal impact on the workpiece, high-precision galvanometer marking head can ensure fine and repeatable marking, high-precision fine spot to ensure the perfect marking results, The marking process is non-contact, the marking effect is permanent.
2. UV laser engraver machine has a large marking range.
3. Heat affected area is very small, there will be no thermal effect, the material is not deformed and charred.
4. High speed and high efficiency.
5. Machine performance is stable, small size, low power consumption.
6. The UV laser engraving machine is suitable for heat radiation reaction of large materials processing, if it's used for the production line with the automatic loading and unloading, it can realize automatic access to materials. It's suitable for the vast majority of metal and non-metallic materials on the marking industry.

Notable Features

① JPT SEAL355 Laser Source: With an advanced beam quality, stable power output, and higher marking speed, this laser source guarantees remarkable performance. It offers an exceptional service life of 100,000 hours and includes free replacement within 2 years.

② Reliable Galvanometer: Equipped with an imported high-speed galvanometer scanning head, this machine achieves a marking speed of up to 8m/s. It boasts a high rate of electrical-optical conversion of up to 70%, ensuring high precision, efficiency, and a long lifespan.

③ Controller and Software: The machine comes with the newest upgraded EZCAD 2.0 controller, which is compatible with Lightburn. It supports multiple languages and offers easy operation. Additionally, it is compatible with Windows XP/Vista/7/8/10.

④ Stable F-theta Lens: Featuring energy uniformity, little attenuation, and a small focus spot, the stable F-theta lens enables deep edge marking. With various working area options, including 90×90mm, 110×110mm, 150×150mm, 175×175mm, 220×220mm, and 300×300mm, it provides flexibility to suit your specific needs.

Upgrade your marking and engraving capabilities with the MCWlaser 3W 5W UV Laser Marking Engraving Machine. Experience reliable performance, user-friendly operation, and outstanding support. Place your order today and benefit from our exceptional door-to-door service with free delivery.

Metal, Glass, Plastic, Wood, Leather, Acrylic, Cloth, Ceramics,Purple sand, Plating film surface, etc. Not sure,contact with us.
Application industries: LCD screen, optical devices, auto glass, hardware,glasses and clocks, precision electronics, instruments, PCB boards and control panels, etc.

D80 Rotary axis (Please contact us if you need it)

• 80mm (3.15in) three-jaw rotary axis + drive.
• 57/76 Stepper motor; 1m long cord, 4 pins and 1 spare spring.
• Internal clamping range:2-22mm; external clamping range:22-63mm.
• 180° rotary positioning;elevation angle 45°/90°.
• Stainless steel material; Quick clamping. Synchronous wheel drive;Effectively eliminate jtter. Rotary spring clamping, fast mounting and dismounting to improve work efficiency.
• ​​​​Industrial standard interface,use aviation plug fits various board card.
• Be mainly for cuboid and circular objects, such as rings, pen, bearinge,bracelets,hardware,etc.
• Other rotation axis optional: 69mm,100mm,125mm,160mm,200mm,300mm.
